2SB 1274R
Κωδικός προϊόντος: 100.102.0683Διαθεσιμότητα: Διαθέσιμο
Silicon PNP-transistor 60v 3a 30w 100MHz To-220.
Τιμή: 8,00 €
Χαρακτηριστικά:
Type Designator: 2SB1274
Material of Transistor: Si
Polarity: PNP
Maximum Collector Power Dissipation (Pc): 30 W
Maximum Collector-Base Voltage |Vcb|: 60 V
Maximum Collector-Emitter Voltage |Vce|: 60 V
Maximum Emitter-Base Voltage |Veb|: 6 V
Maximum Collector Current |Ic max|: 3 A
Max. Operating Junction Temperature (Tj): 150 °C
Transition Frequency (ft): 100 MHz
Collector Capacitance (Cc): 60 pF
Forward Current Transfer Ratio (hFE), MIN: 70
Noise Figure, dB: -
Package: TO220
Κατασκευαστής: n/a Κατηγορία: 2SB
